Notes to self on writing midi files in R

Mostly a scratchpad of bits of code.

from diffusers import DiffusionPipeline
from transformers import set_seed
from PIL import Image
import torch
import random
import ssl
import os
ssl._create_default_https_context = ssl._create_unverified_context

#locate library
#model_id = "./stable-diffusion-v1-5"
model_id = "dreamshaper-xl-turbo"

pipeline = DiffusionPipeline.from_pretrained(
    pretrained_model_name_or_path = "../../../../bigFiles/huggingface/dreamshaper-xl-turbo/"
)

pipeline = pipeline.to("mps")

# Recommended if your computer has < 64 GB of RAM
pipeline.enable_attention_slicing("max")

prompt = "MIDI. Midi music technology. synthwave. 80s. rad cartoon."

for s in range(30):
  for n in [5,10]:
    seed = s+21
    num_steps = n+1
    set_seed(seed)

    image = pipeline(prompt,height = 1024,width = 1024,num_images_per_prompt = 1,num_inference_steps=num_steps)

    image_name = "images/synth_{}_{}.jpeg"

    image_save = image.images[0].save(image_name.format(seed,num_steps))

MIDI. Midi music technology. synthwave. 80s. rad cartoon. - Dreamshaper v7

I’m working on some goals with respect to programming midi files in R. This post is mostly a scratch pad to try out some code.

Some goals.

• Code some bars of music in a tibble.
• try to coerce the tibble into a midi format

Each bar has 1 arpeggiated triad, followed by a chord. Each note will be quarter notes.

library(pyramidi)
library(tidyverse)

# set tempo
BPM_to_microsecond_tempo <- function(BPM) {
  return(60000000/BPM)
}

# song timing and length parameters
BPM <- 120
midi_tempo <- BPM_to_microsecond_tempo(BPM)
time_signature <- c(4,4)
ticks_per_beat <- 480 #PPQN
bars <- 4
smallest_note_unit <- 32

# function to generate a table of timing intervals
make_timing_tibble <- function(bars, smallest_note_unit, BPM, ticks) {
  tibble(
    intervals = 1:(smallest_note_unit * bars),
    bar = rep(1:bars, each = smallest_note_unit),
    quarter = rep(rep(1:4, each = smallest_note_unit/4),bars),
    eighth = rep(rep(1:8, each = smallest_note_unit/8),bars),
    sixteenth = rep(rep(1:16, each = smallest_note_unit/16),bars),
    thirty_two = rep(rep(1:32, each = smallest_note_unit/32),bars),
    interval_ticks = ticks_per_beat/smallest_note_unit,
    elapsed_time = cumsum(interval_ticks)
  )
}

time_tibble <- make_timing_tibble(4,32,120,ticks_per_beat)

# grab midi_defs from pyramidi, put into a names character vector
midi_notes <- 1:dim(midi_defs)[1]
names(midi_notes) <- midi_defs$note_name

time_tibble <- make_timing_tibble(bars = 4,
                                  smallest_note_unit = 4,
                                  BPM = 120,
                                  ticks_per_beat)

BPM <- 120
midi_tempo <- BPM_to_microsecond_tempo(BPM)
time_signature <- c(4, 4)
ticks_per_beat <- 480 #PPQN
bars <- 4
smallest_note_unit <- 4

time_tibble <- tibble(
  intervals = 1:(smallest_note_unit * bars),
  bar = rep(1:bars, each = smallest_note_unit),
  quarter = rep(rep(1:4, each = smallest_note_unit / 4), bars),
  interval_ticks = ticks_per_beat,
  elapsed_time = cumsum(interval_ticks),
  interval_on = elapsed_time - interval_ticks
)

notes_to_play <- list(
  list(note = "C4", note_length = 1),
  list(note = "E4", note_length = 1),
  list(note = "G4", note_length = 1),
  list(note = c("C4", "E4", "G4"), note_length = c(1,1,1)),
  list(note = "D4", note_length = 1),
  list(note = "F4", note_length = 1),
  list(note = "A4", note_length = 1),
  list(note = c("D4", "F4", "A4"), note_length = c(1,1,1)),
  list(note = "E4", note_length = 1),
  list(note = "G4", note_length = 1),
  list(note = "B4", note_length = 1),
  list(note = c("E4", "G4", "B4"), note_length = c(1,1,1)),
  list(note = "F4", note_length = 1),
  list(note = "A4", note_length = 1),
  list(note = "C5", note_length = 1),
  list(note = c("F4", "A4", "C5"), note_length = c(1,1,1))
  )

for(i in 1:length(notes_to_play)){
  if(length(notes_to_play[[i]]$note) == 1){
    notes_to_play[[i]]$start_time <- time_tibble$interval_on[i]
    notes_to_play[[i]]$off_time <- time_tibble$elapsed_time[i]
  }
  if(length(notes_to_play[[i]]$note) > 1){
    notes_to_play[[i]]$start_time <- rep(time_tibble$interval_on[i],length(notes_to_play[[i]]$note))
    notes_to_play[[i]]$off_time <- rep(time_tibble$elapsed_time[i],length(notes_to_play[[i]]$note))
  }
}

---

matrix coding

Example of coding C major scale in a note by time matrix, and then concatenating down to note, time, and note x time vectors.

This strategy ignores note length

#empty matrix containing rows for every possible note
#columns for every possible 64th note over 1 bar
one_bar <- matrix(0,
                  nrow=dim(pyramidi::midi_defs)[1],
                  ncol=64)

# assign rows note names
row.names(one_bar) <- pyramidi::midi_defs$note_name

# define notes to add to play C major scale up and down
notes_to_play <- c("C4","D4","E4","F4","G4","A4","B4","C5",
                   "C5","B4","A4","G4","F4","E4","D4","C4")
times_to_play <- seq(1,64,4)

# assign notes to the one_bar matrix
for(i in 1:length(notes_to_play)){
  one_bar[notes_to_play[i],times_to_play[i]] <- 1
}

#create pitch, time, and pitch x time vectors
pitch_vector <- rowSums(one_bar)
time_vector <- colSums(one_bar)
pitch_by_time <- c(one_bar)

#concatenate_vector
music_vector <- c(pitch_vector,time_vector,pitch_by_time)

midi to matrix

It should be fairly straightforward to get a midi file into the matrix format above.

This worked I think. I’m experimenting the mario file, but the principles here should be useful for a few different endeavors.

Again ignoring note length.

library(pyramidi)
library(dplyr)
library(tidyr)
library(purrr)

#import midi using miditapyr
test_midi <- pyramidi::miditapyr$MidiFrames("overworld.mid")

#import using mido
mido_import <- pyramidi::mido$MidiFile("overworld.mid")

# to R dataframe
dfc <- pyramidi::miditapyr$frame_midi(mido_import)
ticks_per_beat <- mido_import$ticks_per_beat

# unnest the dataframe
df <- pyramidi::miditapyr$unnest_midi(dfc)

# grab track 1
track_1 <- df %>%
  filter(i_track == 1,
         type %in% c("note_on","note_off") ==TRUE) %>%
  mutate(total_time = cumsum(time)) %>%
  filter(type == "note_on")

time_steps <- seq(0,max(track_1$total_time),8)
total_bars <- round(length(time_steps)/48)+1
bars <- rep(1:total_bars,each=48)
bar_steps <- rep(1:48,total_bars)

metric_tibble <- tibble(time_steps = time_steps,
                        bars = bars[1:length(time_steps)],
                        bar_steps =bar_steps[1:length(time_steps)])

track_1 <- track_1 %>%
  mutate(time_markers = which(time_steps %in% total_time),
         bars = 0,
         bar_steps = 0)

# get bar divisions, add them to track_1

for(i in 1:dim(track_1)[1]){
  get_timestep <- time_steps[track_1$time_markers[i]]
  track_1$bars[i] <- metric_tibble %>%
    filter(time_steps == get_timestep) %>%
    pull(bars)
  track_1$bar_steps[i] <- metric_tibble %>%
    filter(time_steps == get_timestep) %>%
    pull(bar_steps)
}

# assign intervals to the bars

music_matrix <- matrix(0,
                       ncol = (48+128+(48*128)),
                       nrow = max(track_1$bars)
)

for(i in 1:max(track_1$bars)){

  bar_midi <- track_1%>%
    filter(bars == i)

  one_bar <- matrix(0,
                  nrow=dim(pyramidi::midi_defs)[1],
                  ncol=48)

  for(j in 1:dim(one_bar)[1]){
    one_bar[bar_midi$note[j],bar_midi$bar_steps[j]] <- 1
  }


  pitch_vector <- rowSums(one_bar)
  time_vector <- colSums(one_bar)
  pitch_by_time <- c(one_bar)

  #concatenate_vector
  music_vector <- c(pitch_vector,time_vector,pitch_by_time)

  music_matrix[i,] <- music_vector

}

I would like to be able to convert back to midi.

# select out one concatenated bar vector
one_bar_vector <- music_matrix[1,(128+48+1):dim(music_matrix)[2]]

#reconstitute matrix
one_bar_matrix <- matrix(one_bar_vector,
                         nrow=128,
                         ncol=48,
                         byrow=F)

#filter for notes and times
note_times <- which(one_bar_matrix == 1, arr.ind=T)
colnames(note_times) <- c("note_num","bar_step")

# convert back to midi time in ticks
note_times <- as_tibble(note_times)
note_times <- note_times %>%
  mutate(ticks = (bar_step *8) -8,
         note_id = 1:n(),
         note_on = ticks,
         note_off = ticks+8) %>%
  pivot_longer(cols = c("note_on","note_off"),
               names_to = "type",
               values_to = "cumulative_ticks") %>%
  arrange(cumulative_ticks) %>%
  mutate(time = cumulative_ticks - lag(cumulative_ticks, default = 0))


# compose midi tibble
midi_bar <- df[1,]
midi_bar <- midi_bar[-1,]

midi_bar <- midi_bar %>%
  add_row(type = note_times$type,
          time = note_times$time,
          note = note_times$note_num) %>%
  mutate(
    i_track = 1,
    meta = FALSE,
    numerator = NaN,
    denominator = NaN,
    clocks_per_click = NaN,
    notated_32nd_notes_per_beat = NaN,
    tempo = NaN,
    name = NA,
    control = NaN,
    value = NaN,
    channel = 0,
    program = NaN,
    velocity = 64
         )

# get meta messages
meta_midi  <- df %>%
  filter(meta ==TRUE,
         i_track == 1)

# merge bar midi into full midi file
midi_track <- meta_midi %>%
  add_row(midi_bar,.after = 3)

Test to see if the bar of midi reconstructed from the matrix can be played back. Seems to work.

mod_df <- midi_track

# update df
test_midi$midi_frame_unnested$update_unnested_mf(mod_df)

# write midi file

test_midi$write_file("mario_bar.mid")

#########
# bounce

track_name <- "mario_bar"

wav_name <- paste0(track_name,".wav")
midi_name <- paste0(track_name,".mid")
mp3_name <- paste0(track_name,".mp3")

# write the midi file to disk
#miditapyr$write_midi(dfc, ticks_per_beat, midi_name)

# synthesize midi file to wav with fluid synth
system_command <- glue::glue('fluidsynth -F {wav_name} ~/Library/Audio/Sounds/Banks/FluidR3_GM.sf2 {midi_name}')
system(system_command)

# convert wav to mp3
av::av_audio_convert(wav_name,mp3_name)

# clean up and delete wav
if(file.exists(wav_name)){
  file.remove(wav_name)
}

try stuff

#import midi using miditapyr
test_midi <- pyramidi::miditapyr$MidiFrames("overworld.mid")

#import using mido
mido_import <- pyramidi::mido$MidiFile("overworld.mid")

# to R dataframe
dfc <- pyramidi::miditapyr$frame_midi(mido_import)
ticks_per_beat <- mido_import$ticks_per_beat

# unnest the dataframe
df <- pyramidi::miditapyr$unnest_midi(dfc)

# compose midi tibble
all_midi_bars <- df[1,]
all_midi_bars <- all_midi_bars[-1,]

for(i in 1:32){

sum_music <- colSums(music_matrix)
sum_music <- sum_music[(48+128+1):length(sum_music)]
prob_music <- sum_music/sum(sum_music)

prob_bar <- rbinom(6144,8,prob_music)
prob_bar[prob_bar > 1] <- 1
#sum(prob_bar)
#plot(prob_bar)

#reconstitute matrix
one_bar_matrix <- matrix(prob_bar,
                         nrow=128,
                         ncol=48,
                         byrow=F)

#filter for notes and times
note_times <- which(one_bar_matrix == 1, arr.ind=T)
colnames(note_times) <- c("note_num","bar_step")

# convert back to midi time in ticks
note_times <- as_tibble(note_times)
note_times <- note_times %>%
  mutate(ticks = (bar_step *8) -8,
         note_id = 1:n(),
         note_on = ticks,
         note_off = ticks+8) %>%
  pivot_longer(cols = c("note_on","note_off"),
               names_to = "type",
               values_to = "cumulative_ticks") %>%
  arrange(cumulative_ticks) %>%
  mutate(time = cumulative_ticks - lag(cumulative_ticks, default = 0))

midi_bar <- df[1,]
midi_bar <- midi_bar[-1,]

midi_bar <- midi_bar %>%
  add_row(type = note_times$type,
          time = note_times$time,
          note = note_times$note_num) %>%
  mutate(
    i_track = 1,
    meta = FALSE,
    numerator = NaN,
    denominator = NaN,
    clocks_per_click = NaN,
    notated_32nd_notes_per_beat = NaN,
    tempo = NaN,
    name = NA,
    control = NaN,
    value = NaN,
    channel = 0,
    program = NaN,
    velocity = 64
         )

all_midi_bars <- rbind(all_midi_bars,midi_bar)

}

# get meta messages
meta_midi  <- df %>%
  filter(meta ==TRUE,
         i_track == 1)

# merge bar midi into full midi file
midi_track <- meta_midi %>%
  add_row(all_midi_bars,.after = 3)

##########################
# bounce

mod_df <- midi_track

# update df
test_midi$midi_frame_unnested$update_unnested_mf(mod_df)

# write midi file

test_midi$write_file("mario_Pbar.mid")

#########
# bounce

track_name <- "mario_Pbar"

wav_name <- paste0(track_name,".wav")
midi_name <- paste0(track_name,".mid")
mp3_name <- paste0(track_name,".mp3")

# write the midi file to disk
#miditapyr$write_midi(dfc, ticks_per_beat, midi_name)

# synthesize midi file to wav with fluid synth
system_command <- glue::glue('fluidsynth -F {wav_name} ~/Library/Audio/Sounds/Banks/nintendo_soundfont.sf2 {midi_name}')
system(system_command)

# convert wav to mp3
av::av_audio_convert(wav_name,mp3_name)

# clean up and delete wav
if(file.exists(wav_name)){
  file.remove(wav_name)
}

all voices

library(pyramidi)
library(dplyr)
library(tidyr)
library(purrr)
#import midi using miditapyr
test_midi <- pyramidi::miditapyr$MidiFrames("all_overworld.mid")

#import using mido
mido_import <- pyramidi::mido$MidiFile("all_overworld.mid")

# to R dataframe
dfc <- pyramidi::miditapyr$frame_midi(mido_import)
ticks_per_beat <- mido_import$ticks_per_beat

# unnest the dataframe
df <- pyramidi::miditapyr$unnest_midi(dfc)

##############################################
# convert to matrix

# grab track 1
track_1 <- df %>%
  filter(i_track == 0,
         type %in% c("note_on","note_off") ==TRUE) %>%
  mutate(total_time = cumsum(time)) %>%
  filter(type == "note_on")

time_steps <- seq(0,max(track_1$total_time),8)
total_bars <- round(length(time_steps)/48)+1
bars <- rep(1:total_bars,each=48)
bar_steps <- rep(1:48,total_bars)

metric_tibble <- tibble(time_steps = time_steps,
                        bars = bars[1:length(time_steps)],
                        bar_steps =bar_steps[1:length(time_steps)])

track_1 <- track_1 %>%
  mutate(time_markers = 0,
         bars = 0,
         bar_steps = 0)

for(i in 1:dim(track_1)[1]){
  track_1$time_markers[i] <- which(time_steps %in% track_1$total_time[i])
}

# get bar divisions, add them to track_1

for(i in 1:dim(track_1)[1]){
  get_timestep <- time_steps[track_1$time_markers[i]]
  track_1$bars[i] <- metric_tibble %>%
    filter(time_steps == get_timestep) %>%
    pull(bars)
  track_1$bar_steps[i] <- metric_tibble %>%
    filter(time_steps == get_timestep) %>%
    pull(bar_steps)
}

# assign intervals to the bars

music_matrix <- matrix(0,
                       ncol = (48+128+(48*128)),
                       nrow = max(track_1$bars)
)

for(i in 1:max(track_1$bars)){

  bar_midi <- track_1%>%
    filter(bars == i)

  one_bar <- matrix(0,
                  nrow=dim(pyramidi::midi_defs)[1],
                  ncol=48)

  for(j in 1:dim(one_bar)[1]){
    one_bar[bar_midi$note[j],bar_midi$bar_steps[j]] <- 1
  }


  pitch_vector <- rowSums(one_bar)
  time_vector <- colSums(one_bar)
  pitch_by_time <- c(one_bar)

  #concatenate_vector
  music_vector <- c(pitch_vector,time_vector,pitch_by_time)

  music_matrix[i,] <- music_vector

}

#########################################

# compose midi tibble
all_midi_bars <- df[1,]
all_midi_bars <- all_midi_bars[-1,]

for(i in 1:32){

sum_music <- colSums(music_matrix)
sum_music <- sum_music[(48+128+1):length(sum_music)]
prob_music <- sum_music/sum(sum_music)

#mean(rowSums(music_matrix[,(48+128+1):dim(music_matrix)[2]]))

prob_bar <- rbinom(length(sum_music),48,prob_music)
prob_bar[prob_bar > 1] <- 1
#sum(prob_bar)
#plot(prob_bar)

#reconstitute matrix
one_bar_matrix <- matrix(prob_bar,
                         nrow=128,
                         ncol=48,
                         byrow=F)

#filter for notes and times
note_times <- which(one_bar_matrix == 1, arr.ind=T)
colnames(note_times) <- c("note_num","bar_step")

# convert back to midi time in ticks
note_times <- as_tibble(note_times)
note_times <- note_times %>%
  mutate(ticks = (bar_step *8) -8,
         note_id = 1:n(),
         note_on = ticks,
         note_off = ticks+8) %>%
  pivot_longer(cols = c("note_on","note_off"),
               names_to = "type",
               values_to = "cumulative_ticks") %>%
  arrange(cumulative_ticks) %>%
  mutate(time = cumulative_ticks - lag(cumulative_ticks, default = 0))

midi_bar <- df[1,]
midi_bar <- midi_bar[-1,]

midi_bar <- midi_bar %>%
  add_row(type = note_times$type,
          time = note_times$time,
          note = note_times$note_num) %>%
  mutate(
    i_track = 0,
    meta = FALSE,
    numerator = NaN,
    denominator = NaN,
    clocks_per_click = NaN,
    notated_32nd_notes_per_beat = NaN,
    tempo = NaN,
    name = NA,
    control = NaN,
    value = NaN,
    channel = 0,
    program = NaN,
    velocity = 64
         )

all_midi_bars <- rbind(all_midi_bars,midi_bar)

}

# get meta messages
meta_midi  <- df %>%
  filter(meta ==TRUE,
         i_track == 0) %>%
  mutate(tempo = NaN) %>%
  add_row(
    i_track = 0,
    time = 0,
    meta = TRUE,
    type = "set_tempo",
    tempo = 500000,
    .before = 2
  )

# merge bar midi into full midi file
midi_track <- meta_midi %>%
  add_row(all_midi_bars,.after = 3)

##########################
# bounce

mod_df <- midi_track

# update df
test_midi$midi_frame_unnested$update_unnested_mf(mod_df)

# write midi file

test_midi$write_file("mario_P_allbar.mid")

#########
# bounce

track_name <- "mario_P_allbar"

wav_name <- paste0(track_name,".wav")
midi_name <- paste0(track_name,".mid")
mp3_name <- paste0(track_name,".mp3")

# write the midi file to disk
#miditapyr$write_midi(dfc, ticks_per_beat, midi_name)

# synthesize midi file to wav with fluid synth
system_command <- glue::glue('fluidsynth -F {wav_name} ~/Library/Audio/Sounds/Banks/nintendo_soundfont.sf2 {midi_name}')
system(system_command)

# convert wav to mp3
av::av_audio_convert(wav_name,mp3_name)

# clean up and delete wav
if(file.exists(wav_name)){
  file.remove(wav_name)
}
